Enclosures

made of ABS, polycarbonate, polyester, aluminum and stainless steel for use in industrial as well as hazardous areas.

Enclosures - gladly also finished and equipped

Whether enclosures made of plastic, aluminum or stainless steel: RST offers solutions for almost all requirements - regardless of whether industrial application or use in hazardous areas. We are happy to machine, wire and assemble the enclosures directly, e.g. with terminal blocks, connectors or cable glands. We follow the individual specifications of our customers (e.g. parts lists). In this context, please also refer to the detailed explanations in the section on cable assemblies:

cable assemblies



Are you looking for a partner who can supply you not only with individual components but also, if possible, with a fully assembled system? Then you have come to the right place:

ENCLOSURE ASSEMBLY

EX ENCLOSURE PES

Material:Polyester, Graphite Added (glass fibre reinforced/thermoset)
Sealing:Silicone
Protection Class:IP66
Colour:RAL 9011

Approvals / Test Reports / Declarations

Something missing? Then please contact us!

You can find an article-specific allocation of approvals at article level or in the cross-reference list.

Data Sheets / Installation Instructions

Something missing? Then please contact us!

Mounting Instruction
Ex ia Enclosure
Material: Polyester, Graphite Added (glass fibre reinforced/thermoset)
Article NumberLengthWidthHeight
1808080600080.0075.0055.00
1808080800080.0075.0075.00
18110806000110.0075.0055.00
18110808000110.0075.0075.00
18121209000122.00120.0090.00
18160806000160.0075.0055.00
18160808000160.0075.0075.00
18161609000160.00160.0090.00
18190806000190.0075.0055.00
18190808000190.0075.0075.00
18221209000220.00120.0090.00
18230806000230.0075.0055.00
18230808000230.0075.0075.00
18261609000260.00160.0090.00
18262512000255.00250.00120.00
18262516000255.00250.00160.00
18361609000360.00160.0090.00
18363609000360.00360.0090.00
18402512000400.00250.00120.00
18402516000400.00250.00160.00
18404112000400.00405.00120.00
18561609000560.00160.0090.00
18602512000600.00250.00120.00
Unless otherwise stated, all data in millimeters or pieces (quantity)
* Minimum order quantity (MOQ) can be larger than packaging unit (PU).
